LAB INFORMATION
| Sr. No. | Lab Name | Lab Incharge Name | Room No. | Area (Sq M.) | Major Equipment |
|---|---|---|---|---|---|
| 1 | Digital communication Laboratory | A. M. Wandhare | S64 | 637.5 Sq. Ft. |
1) Antenna 2) Caddo 803 30MHz 2 Channel 4-Trace Microcontroller Based Oscilloscope with digital readout on LCD Display for (V/div) 3) Elementary Fiber Optic 4) Microwave Test Bench (Klystron Based) 5) Colour Tv (36 cm) 6) Two channel code division multiple access (DSSS and FHSS) |
| 2 | Applied Electronics Laboratory | A. M. Wandhare | S64 | 695.6 Sq. Ft. |
1) Scientech ST 2612 Analog Lab (supplied with handheld Digital Multimeter) 2) Caddo 803 30MHz 2 Channel 4-Trace Microcontroller Based Oscilloscope with digital readout on LCD Display for (V/div) 3) Speed control of AC Servo Motor with Tachometer NV7043 |
| 3 | Digital and Microcontroller Laboratory | K. K. Janjarlawar | F68 | 373.76 Sq. Ft. |
1) NV5001 Microcontroller Development Board with Programmer 2) NV5585A Advanced 8085 Microprocessor Trainer |
| 4 | Measurement and control Laboratory | K. K. Janjarlawar | S63 | 896 Sq. Ft. |
1) Synchro Transmitter and Receiver 2) Control System Simulator 3) Spectrum analyser |
| 5 | Electronics and workshop Laboratory | V. A. Guntikwar | S65 | 669.6 Sq.Ft | Caddo 9304 Hand Held Digital LCR metre |
| 6 | Computer Laboratory | K. K. Janjarlawar | S62 | 307.2 Sq.ft | 1) PC Set 20 Hp, Desktop 17 G-14, RAM-16Gb, SSD-512, PowerSupply(SMP)-280w 2.10GHz Monitor 21.5” FULL HD USB Keyboard And Mouse. |
LAB PHOTOS
LAB 1 - Digital communication Laboratory
LAB 2 - Applied Electronics Laboratory
LAB 3 - Digital and Microcontroller Laboratory
LAB 4 - Measurement and control Laboratory
LAB 5 - Electronics and workshop Laboratory
LAB 6 - Computer Laboratory
