LAB INFORMATION
| Sr. No. | Lab Name | Lab Incharge | Room No. | Area | Major Equipment |
|---|---|---|---|---|---|
| 1 | ELECTRICAL AC & DC MACHINE LAB | Mr.A.D.THAKRE | F 86 | 104 Sq M |
1) DC MOTOR TRAINER 3 HP 2) DC SERIES MOTOR – GENERATOR SET 1 HP 3) THREE PHASE SYNCHRONOUS MOTOR 4) SLIP RING INDUCTION MOTOR 5) THREE PHASE SYNCHRONOUS LAB 2 HP DC SHUNT MOTOR – 3 HP Generator 6) SQUIRREL CAGE INDUCTION MOTOR – SHUNT GENERATOR |
| 2 | CAD LAB | Ms.S.S.BONDE | F 85 | 66 Sq M | SET OF 20 PC , RAM 16 GB, 128GB SSD, WINDOWS 11 6th GEN, D-LINK ROUTER |
| 3 | BASIC ELECTRICAL ENGINEERING LAB | Mr.A.DHOMADE | F 84 | 66 Sq M |
1) POWER MEASUREMENT BY TWO WATTMETER METHOD 2) POWER MEASUREMENT BY TWO WATTMETER METHOD 3) ENERGY METER TRAINER |
| 4 | ELECTRICAL & ELECTRONICS MEASUREMENT LAB | Ms.D.P.MAHULIKAR | F 83 | 66 Sq M |
1) POWER MEASUREMENT BY TWO WATTMETER METHOD 2) POWER MEASUREMENT BY TWO WATTMETER METHOD 3) ENERGY METER TRAINER |
| 5 | SWITCH GEAR & PROTECTION LAB | Ms.S.V.SATPUTE | F 82 | 66 Sq M |
1) OVERCURRENT RELAY TESTING SYSTEM 2) ELECTRICAL SAFETY TRAINER |
| 6 | ELECTRICAL CIRCUIT & NETWORK LAB | Ms.M.M.SUMATKAR | F 81 | 66 Sq M |
1) RLC SERIES & PARALLEL RESONANCE TRAINER 2) KIRCHOFF CURRENT & VOLTAGE POWER SUPPLY 3) NETWORK THEOREM TRAINER 1 4) NETWORK THEOREM TRAINER 2 |
| 7 | BASIC ELECTRICAL WORKSHOP LAB | Mr.N.S.SIDDIQUI | F 80 | 66 Sq M |
LAB PHOTOS
ELECTRICAL AC & DC MACHINE LAB
SWITCH GEAR AND PROTECTION LAB
ELECTRICAL CIRCUIT AND NETWORK LAB
ELECTRICAL AND ELECTRONICS WORKSHOP
BASIC ELECTRICAL ENGINEERING LAB
ELECTRICAL AND ELECTRONICS MEASUREMENT LAB
CAD / CAM LAB
